MOSFET SOT-23 P-Channel BSS84-Topdiode
- -60V,-170mA
- RDs(ON),<8.0 Ω @VGS=10V
- RDs ON,<10 Ω @VGS=4.5V
- Advanced Trench Technology
- Low RDS(ON)
- Low Gate Charge
MOSFET SOT-23 P-Channel BSS84-Topdiode
Topdiode BSS84 is a P−channel enhancement MOSFET which is produced by using Topdiode’s proprietary, high cell density technology.
This very high density process minimizes on−stateresistance and to provide rugged and reliable performance and fastswitching.
It’s particularly suited to low−voltage applications requiring a low−current high−side switch.
Topdiode BSS84 is a nice alternative offer for On semi/Diodes MOSFET BSS84.
MOSFET SOT-23 P-Channel BSS84-Topdiode DATA
- Tab
| Parameter | Symbol | Value | Unit |
| Drain-Source Voltage | VDS | -60 | V |
| Gate-Source Voltage | VGS | ±20 | V |
| Continuous Drain Current (Ta =25℃) | ID | -170 | mA |
| Continuous Drain Current (Ta=70℃) | ID | -140 | mA |
| Pulsed Drain Current | IDM | -0.68 | A |
| Power Dissipation | PD | 0.225 | W |
| Thermal Resistance from Junction to Ambient(4) | RθJA | 556 | ℃/W |
| Junction Temperature | TJ | 150 | ℃ |
| Storage Temperature | TSTG | -55~+150 | ℃ |
